‘S’ Type Plug

12S 7 Pin Towing Plug

Specification

• Durable plastic construction
• Screw type terminals for easy wiring
• Brass pins
• Wiring diagram:
• Pin 1 Yellow – Reversing lamps
• Pin 2 Blue – Battery charging
• Pin 3 White – Earth return (for pins 2 & 4)
• Pin 4 Green – Power supply
• Pin 5 Brown – Spare
• Pin 6 Red – Fridge
• Pin 7 Black – earth return (for pin 6)
• Qty: 1
• Colour: Grey

RI501
